Brass Anti

Basic Info.

Model NO.	NRL001
Driving Mode	Manual
Nominal Pressure	ANSI CLASS 150-900
Channel	Straight Through Type
Structure	Fixed Ball Valve
Type	Fixed Ball Valve
Function	Relief Valve
Temperature	Normal Temperature
Standard	Bsen 13828-2003
Application	Industrial Usage, Water Industrial Usage
Advantage	with a Lockable Cap
HS	8481804090
Color	Brass Natural Color
Size	1/2" to 2"
Transport Package	Inner Box/Outer Carton
Specification	1/2" to 2"
Trademark	NRCI
Origin	Made in China
HS Code	8481804090
Production Capacity	50000PCS/Month

Packaging & Delivery

Package Size 20.00cm * 20.00cm * 15.00cm Package Gross Weight 15.000kg

Product Description

Brass Ball valves, magnetic lockable ball valve, lockable ball valve.
Forged valve, Hydraulic valve
Brass body. Brass Chromed plate ball
Size: 1/2"~2"
Body: Hot pressed from dezincification resistant brass bar
Ball: Hot pressed from dezincification resistant brass bar - Hard chromium plated
Ball gaskets in PTFE
This tamper-proof valve is designed with a double-locking system, made of brass. Once secured, a special key is needed to unlock the valve. The lockable ball valve consists of a brass body, chromed-brass ball and chromed magnetic lock.

Material	Brass Body, Brass Bonnet, brass ball, steel handle Brass can be CZ132,CZ122,CW602,CW617N,C36000, DZR, etc
Surface	Natural brass or Nickel plated
Size	1/2" To 2"
Testing Pressure	100% tested with 0.6MPa - 0.8MPa by air.
Suitable medium	Water, no-causticity liquid, and gas
Working temperature	-20 to 120° C
Thread	Compression end and BSP & NPT Female x female or MalexM,FxM for selecting
Samples Time	1) 2 days - For our existing samples for reference 2) 30 days - If new size, need make the new mould
OEM Acceptable	Yes
Production Capacity	50000pcs each month
Packing Details	Poly bag, inner box, out carton and pallet.
Payment Term	T/T ,L/C,WESTERN UNION
Delivery Time	30 days to 40 days after confirming all details
Minimum Order Quantity	500-2000 Pieces
